6kgs 8M2 Submerged Membrane Bioreactor Mbr Biological Treatment
  • 6kgs 8M2 Submerged Membrane Bioreactor Mbr Biological Treatment
  • 6kgs 8M2 Submerged Membrane Bioreactor Mbr Biological Treatment
  • 6kgs 8M2 Submerged Membrane Bioreactor Mbr Biological Treatment

6kgs 8M2 Submerged Membrane Bioreactor Mbr Biological Treatment

Place of Origin China
Brand Name CNKHONG
Model Number KH-MBR-8-Co-PVDF
Product Details
Material:
Reinforced PVDF
OD/ID:
2.2/1.0mm
Size:
1050x645x47mm
Flux Rate:
15-20LMH
Transmembrane Pressure:
-0.08MPa
Temperature Scope:
1-40C
High Light:

8M2 submerged membrane bioreactor

,

6kgs submerged membrane bioreactor

,

PVDF material mbr biological treatment

Product Description

8M2 MBR Membrane Elements for Wastewater Treatment with PVDF material



Submerged MBR Membrane Modules for Sludge Treatment with PVDF material



MBR (Membrane Biological Reactor), is a new waste water treatment equipment combining advantages of UF system and biological reactor. Activated sludge and microorganism in it will absorb and resolve organic pollutant in waste water, leave pure water. UF membrane is to separate water and mud, can replace second setting pond. Meanwhile, membrane keeps activated sludge microorganism in biological reactor for long time, make a high biological concentration which means high oxygenation efficiency of microorganism to organics.



Applications:

It can be used for municipal sewage and industrial waste water treatment and substitute for secondary sedimentation tank in removing suspended particles, so as to increase nitrogen removal rate and organics degradation rate.



Youber hollow fiber MBR membrane module can be widely used in various waste water processes with high BOD and suspended solids content, including the following:

1)Municipal drainage treatment

2)Industrial waste water treatment, including chemical and food processing waste water etc.

3)Waste water treatment in aquaculture plants

4)Waste Penetration Treatment

5)Treatment and reuse of pharmaceutical waste water



3. Technical Parameter of Membrane Module



Item/Model KH-MBR-6-CO-PVDF KH-MBR-12-CO-PVDF KH-MBR-15-CO-PVDF
Membrane Area(M2) 8 12 15
Height 1050 mm 1550 mm 1550 mm
Width 645 mm 645mm 645 mm
Thickness 47 mm 47mm 47mm
Dry Weight 6kgs 10kgs 15 kgs
Membrane material Reinforced PVDF Reinforced PVDF Reinforced PVDF
Micro pore size 0.05μm 0.05μm 0.05μm
ID/OD of Membrane 0.9/2.2mm 0.9/2.2mm 0.9/2.2mm
Suspend solid <5mg/L <5mg/L <5mg/L
Temperature 5-40℃ 5-40℃ 5-40℃
PH range 2~11 2~11 2~11
Flux for waste water 15~20 LMH 15~20 LMH 15~20 LMH
Operating Method Sucking out 8 mins and staying 2 mins Sucking out 8 mins and staying 2 mins

Sucking out 8 mins

and staying 2 mins

Cleaning Chemicals 500-3000ppm Sodium hypochlorite 500-3000ppm Sodium hypochlorite

500-3000ppm

Sodium hypochlorite



Item/Model KH-MBR-25-CO-PVDF KH-MBR-30-CO-PVDF KH-MBR-35-CO-PVDF
Membrane Area(M2) 25 30 35
Height 1560 mm 1810 mm 1810 mm
Width 1040 mm 1040 mm 1250 mm
Thickness 47 mm 47mm 35 mm
Dry Weight 20 kgs 25 kgs 30 kgs
Membrane material Reinforced PVDF Reinforced PVDF Reinforced PVDF
Micro pore size 0.05μm 0.05μm 0.05μm
ID/OD of Membrane 0.9/2.2mm 0.9/2.2mm 0.9/2.2mm
Suspend solid <5mg/L <5mg/L <5mg/L
Temperature 5-40℃ 5-40℃ 5-40℃
PH range 2~11 2~11 2~11
Flux for waste water 15~20 LMH 15~20 LMH 15~20 LMH
Operating Method Sucking out 8 mins and staying 2 mins Sucking out 8 mins and staying 2 mins

Sucking out 8 mins

and staying 2 mins

Cleaning Chemicals 500-3000ppm Sodium Hypochlorite

500-3000ppm

Sodium Hypochlorite

500-3000ppm

Sodium hypochlorite



2. Typical parameters of MBR units.



Item/Model KH-MBRMD-8×10 KH-MBRMD-8×20 KH-MBRMD-8×25
Quantity of MBR modules

10 pcs of

MBR-8 modules

20 pcs of

MBR-8 modules

25 pcs of

MBR-8 modules

Total Membrane Area(M2) 80 160 200
Length 876 mm 1676 mm 2100 mm
Width 740 mm 740 mm 750 mm
Height 1300 mm 1300 mm 1300 mm
Estimated Weight 120 kgs 240 kgs 300 kgs



4.Structure of Membrane Modules and Frames:



A. Structure of MBR Modules

6kgs 8M2 Submerged Membrane Bioreactor Mbr Biological Treatment 0











B.Structure of MBR Frames

6kgs 8M2 Submerged Membrane Bioreactor Mbr Biological Treatment 1









5. Product Features



-- All the frames are made of SS 304 or SS 316 stainess steel with reliable frames.

      -- Every modules can be pulled out or putted in very conveniently for they are installed into UPVC Groove from top to bottom.

      -- Every modules have flexible tubes connecting to collecting pipes.

      -- Every modules have independent air blowing tube. There are additional air-blowing tube at the bottom of the frames.

      -- All the modules have an added patented design air blowing tube to enhance the efficiency of the air blowing onto the membrane surface.

      -- Permanent Hydrobility Membrane

      -- Strong strength, the broken strength more than 50MPa



6. Application of MBR Units:

      The whole installation and application process of our MBR modules are described as the following photo:



A. MBR unit of KH-MBRMD-15×28-CO-PVDF with total membrane area of 420 m2/unit.



6kgs 8M2 Submerged Membrane Bioreactor Mbr Biological Treatment 2



6kgs 8M2 Submerged Membrane Bioreactor Mbr Biological Treatment 3







Why Choose US?


1). Over 20 years experience in UF and MBR membrane
2). Excellent cooperation partner
3). Own an excellent technical team
4). Advanced R & D capability
5). International management system(ISO9001)
6). Located in Jiangsu, convenient for export transportation.



Our Service



1). MBR membrane technical consulting,
2). MBR membrane application engineering design,
3). MBR system manufacturing, installation and commissioning,
4). Different membrane dimension, material like PP, PVDF etc.,can be customize according to your requirements
5). 12 months warranty
