2200mm 1875mm Tubular Membrane Module 500ppm PVDF Ultrafiltration Water Treatment

 MBR Membrane Elements for Wastewater Treatment with PVDF material

1. MBR Introduction

MBR System is one kind of waste water treatment device, MBR is its core part, Meanwhile includes air washing system/ clean water washing system/ dosing system and etc. Membrane bio-reactor ( membrane Bio-Reactor, MBR) is a Membrane unit is introduced into traditional sewage biological treatment technology of the new processing technology, Membrane separation unit in replace of traditional secondary sedimentation pool function at the same time, with further removal of organic matter and nitrogen and phosphorus, is currently the most advanced and efficient water treatment technology.

2. Application

1.Domestic wastewater application.
2. Municipal wastewater application.
3.Food and beverage industry application
4.Fermentation industry application
5.Environmental protection industry

3. Technical Parameter of Membrane Module

2. Typical parameters of MBR units.

4.. Structure of Membrane Modules and Frames:

A. Structure of MBR Modules

B.Structure of MBR Frames

5. Product Features

-- All the frames are made of SS 304 or SS 316 stainess steel with reliable frames.

      -- Every modules can be pulled out or putted in very conveniently for they are installed into UPVC Groove from top to bottom.

      -- Every modules have flexible tubes connecting to collecting pipes.

      -- Every modules have independent air blowing tube. There are additional air-blowing tube at the bottom of the frames.

      -- All the modules have an added patented design air blowing tube to enhance the efficiency of the air blowing onto the membrane surface.

      -- Permanent Hydrobility Membrane

      -- Strong strength, the broken strength more than 50MPa

6. Application of MBR Units:

      The whole installation and application process of our MBR modules are described as the following photo:

Why Choose US?

1). Over 20 years experience in UF and MBR membrane
2). Excellent cooperation partner
3). Own an excellent technical team
4). Advanced R & D capability
5). International management system(ISO9001)
6). Located in Jiangsu, convenient for export transportation.

Our Service

1). MBR membrane technical consulting,
2). MBR membrane application engineering design,
3). MBR system manufacturing, installation and commissioning,
4). Different membrane dimension, material like PP, PVDF etc.,can be customize according to your requirements
5). 12 months warranty
