20m2 Domestic Mbr Module Spiral Wound Modules Wastewater Treatment Membrane
  • 20m2 Domestic Mbr Module Spiral Wound Modules Wastewater Treatment Membrane
  • 20m2 Domestic Mbr Module Spiral Wound Modules Wastewater Treatment Membrane
  • 20m2 Domestic Mbr Module Spiral Wound Modules Wastewater Treatment Membrane

20m2 Domestic Mbr Module Spiral Wound Modules Wastewater Treatment Membrane

Place of Origin China
Brand Name CNKHONG
Model Number KH-MBR-20-Co-PVDF
Product Details
Material:
Reinforced PVDF
OD/ID:
2.2/1.0mm
Size:
1810x1250x47mm
Flux Rate:
15-20LMH
Transmembrane Pressure:
-0.08MPa
Temperature Scope:
1-40C
High Light:

20m2 mbr module

,

Domestic ABS Resin mbr module

,

20LMH spiral wound modules

Product Description

20m2 Domestic Wastewater Treatment MBR Membrane Module with PVDF 0.05 pore size



Membrane bioreactor (MBR) is the combination of a membrane process like microfiltration or ultrafiltration with a suspended growth bioreactor, and is now widely used for municipal and industrial wastewater treatment.

Membrane bioreactors can be used to reduce the footprint of an activated sludge sewage treatment system by removing some of the liquid component of the mixed liquor. This leaves a concentrated waste product that is then treated using the activated sludge process.



PVDF MBR Membrane KH-MBR-20-Co-PVDF Specification:



Module KH-MBR-20-Co-PVDF
Membrane materials Reinforced PVDF
Membrane fiber shape Hollow fiber
Permeate ABS Resin
Seal material Polyurethane resin
Element dimensions 1560×1040x47 mm
Effective Membrane area 20.0m2
Pore size 0.01-0.1um
Microporous average aperture 0.1um
PH range 2-12
Suited temperature 5-45
Work pressure 0.02-0.04MPa
Flow rate 10-20L/m2.h
Dia I/O (mm ) 0.6mm/1.2mm
Filtration methods Outside-in
Supports UPVC pipe



Application:



Submerged Membrane Module ,the Reinforced PVDF material MBR Membrane is widely use for industrial and sewage waste water treatment.



Service & Packaging:



Hinada is the professional MBR Membrane manufacturer, we can offer according to client requirement .
Hinada can offer the completely integrated MBR System according to client project





The advantages to using our MBRs include

  1. Massive Footprint reduction

  2. High MLSS operation in Activated sludge process

  3. Increased water treatment rate for a given volume of space

  4. Superior effluent quality

  5. Eliminates need for secondary clarifiers and separate membrane systems

  6. Increased removal of bacteria and Virus

  7. Savings on construction costs

  8. Savings on energy costs

  9. Easy cleaning and maintenance





20m2 Domestic Mbr Module Spiral Wound Modules Wastewater Treatment Membrane 0





20m2 Domestic Mbr Module Spiral Wound Modules Wastewater Treatment Membrane 1











Why Choose US?


1). Over 20 years experience in UF and MBR membrane
2). Excellent cooperation partner
3). Own an excellent technical team
4). Advanced R & D capability
5). International management system(ISO9001)
6). Located in Jiangsu, convenient for export transportation.



Our Service



1). MBR membrane technical consulting,
2). MBR membrane application engineering design,
3). MBR system manufacturing, installation and commissioning,
4). Different membrane dimension, material like PP, PVDF etc.,can be customize according to your requirements
5). 12 months warranty
